Запчасти Komatsu PC1250SP-8R ПРИВОД НАСОС (/7) Y

Схема запчастей Komatsu PC1250SP-8R - ПРИВОД НАСОС (/7) Y
17
18
16
24
14
15
13
22
19
20
21
23
25
5
6
7
8
3
2
4
9
10
1
11
12

Артикул

Название

Примечание

Количество

|$1

708-1L-00800

PUMP ASS'Y

|$2

THIS ASSEMBLY CONSISTS OF ALL PARTS

|$3

SHOWN IN FIGS.Y1600-61A0 TO Y1600-67A0.

|$4

708-1L-01800

PUMP SUB ASS'Y

1

708-2L-34180

SLIDER

|$6

708-2L-06950

VALVE ASS'Y,PC

|$7

708-2L-06960

PISTON ASS'Y,SERVO

2

PISTON,SERVO

3

SCREW

4

708-2L-35680

SEAL

5

708-2L-35230

PLUG

6

708-2L-35690

SEAL

7

708-2L-35170

PIN

8

708-2L-35570

SPOOL

9

708-2L-35630

RETAINER

10

708-2L-35641

SEAT

11

708-2L-35580

SPRING

12

708-2L-35730

SPRING

13

708-2L-34250

SCREW

14

07000-B3034

O-RING

15

708-2L-35210

RING

16

708-2L-35710

SEAL

17

708-2L-35590

PLUG

18

07000-B2010

O-RING

19

07000-B3045

O-RING

20

708-2L-35750

RING

21

708-2L-34230

COVER

22

01580-10806

NUT

23

708-2L-35870

NUT

24

708-2L-35670

RING,WIRE

25

01252-61440

BOLT

Выбрано товаров: 31
