Запчасти Komatsu PC1250SP-8R ПРИВОД НАСОС (/7) Y

|$1

708-1L-00800

PUMP ASS'Y

|$2

THIS ASSEMBLY CONSISTS OF ALL PARTS

|$3

SHOWN IN FIGS.Y1600-61A0 TO Y1600-67A0.

|$4

708-1L-01800

PUMP SUB ASS'Y

1

708-2L-32110

SHAFT,FRONT

2

708-2L-32150

BEARING

3

708-2E-05040

WASHER KIT

|$8

WASHER,3.1MM

|$9

WASHER,3.0MM

|$10

WASHER,2.9MM

|$11

WASHER,2.8MM

4

708-25-12790

RING,SNAP

5

708-25-52861

SEAL,OIL

6

708-2L-22160

SPACER

7

04065-06825

RING,SNAP

|$16

708-2L-06470

BLOCK ASS'Y,FRONT

8

BLOCK,CYLINDER

9

PLATE,VALVE

10

720-68-19610

PIN

11

04065-04818

RING,SNAP

12

708-2L-23131

SEAT

13

708-2L-33160

SPRING

14

708-7L-13140

SEAT

15

708-2L-23351

GUIDE,RETAINER

16

708-2L-23360

PIN

17

708-2L-33350

RETAINER,SHOE

18

708-2L-33430

PISTON SUB ASS'Y

|$28

708-2L-06630

CRADLE ASS'Y

19

CRADLE

20

CAM,ROCKER

21

04020-01228

PIN

22

01252-61230

BOLT
