Запчасти Komatsu PC1250SP-8R ОСНОВН. НАСОС (/)(NO. НАСОС) Y
№
Артикул
Название
Примечание
Количество
|$1
708-2H-00440
PUMP ASS'Y
|$2
THIS ASSEMBLY CONSISTS OF ALL PARTS
|$3
SHOWN IN FIGS.Y1600-41A0 TO Y1600-56A0.
|$4
708-27-09121
SERVO VALVE ASS'Y,FRONT
|$5
708-27-09321
SERVO VALVE SUB A.,FRONT
|$6
708-25-00830
BODY ASS'Y
1
BODY,FRONT
2
EXPANDER
3
708-25-15120
PISTON
4
708-27-25130
SEAT
5
708-27-16310
SPRING
6
708-23-15120
SEAT
7
708-27-16320
SPRING
8
708-23-15160
PLUG
9
07000-B2018
O-RING
10
708-25-15150
COVER
11
01580-10806
NUT
12
708-25-15320
BOLT
13
01602-20619
WASHER
14
708-25-65170
PLUG
15
07002-62034
O-RING
16
07239-12009
NUT
17
708-25-15180
SLEEVE
18
708-25-15280
SPOOL
19
708-25-15310
SPRING
20
708-25-15330
SPACER
21
708-25-15430
PLUG
22
708-25-15340
SCREW
23
07000-B2012
O-RING
24
708-25-15250
COVER
25
01580-10806
NUT
26
708-25-15320
BOLT
27
01602-20619
WASHER
28
708-25-15260
PLUG
29
07002-60823
O-RING
30
708-67-16260
ARM
31
708-25-15360
PIN
32
708-25-15370
WASHER
33
708-25-15380
O-RING
|$1
708-2H-00440
PUMP ASS'Y
|$2
THIS ASSEMBLY CONSISTS OF ALL PARTS
|$3
SHOWN IN FIGS.Y1600-41A0 TO Y1600-56A0.
|$4
708-27-09121
SERVO VALVE ASS'Y,FRONT
|$5
708-27-09321
SERVO VALVE SUB A.,FRONT
|$6
708-25-00830
BODY ASS'Y
1
BODY,FRONT
2
EXPANDER
3
708-25-15120
PISTON
4
708-27-25130
SEAT
5
708-27-16310
SPRING
6
708-23-15120
SEAT
7
708-27-16320
SPRING
8
708-23-15160
PLUG
9
07000-B2018
O-RING
10
708-25-15150
COVER
11
01580-10806
NUT
12
708-25-15320
BOLT
13
01602-20619
WASHER
14
708-25-65170
PLUG
15
07002-62034
O-RING
16
07239-12009
NUT
17
708-25-15180
SLEEVE
18
708-25-15280
SPOOL
19
708-25-15310
SPRING
20
708-25-15330
SPACER
21
708-25-15430
PLUG
22
708-25-15340
SCREW
23
07000-B2012
O-RING
24
708-25-15250
COVER
25
01580-10806
NUT
26
708-25-15320
BOLT
27
01602-20619
WASHER
28
708-25-15260
PLUG
29
07002-60823
O-RING
30
708-67-16260
ARM
31
708-25-15360
PIN
32
708-25-15370
WASHER
33
708-25-15380
O-RING
Выбрано товаров: 78
