Запчасти Komatsu PC1250SP-8R ОСНОВН. НАСОС (7/)(NO. НАСОС) Y

Схема запчастей Komatsu PC1250SP-8R - ОСНОВН. НАСОС (7/)(NO. НАСОС) Y
26
12
25
27
13
11
24
10
22
22
23
8
20
9
5
19
7
6
18
4
30
3
17
31
41
32
40
33
2
39
42
40
43
38
45
44
2
28
36
29
40
37
46
2
1
2
15
14
21
23
16
22
35
34
24
25
27
26

Артикул

Название

Примечание

Количество

|$1

708-2L-00691

PUMP ASS'Y

|$2

708-2L-00690

PUMP ASS'Y

|$3

THIS ASSEMBLY CONSISTS OF ALL PARTS

|$4

SHOWN IN FIGS.Y1600-21A0 TO Y1600-31A0.

|$5

708-25-09191

SERVO VALVE ASS'Y,FRONT

|$6

708-25-00840

BODY ASS'Y

1

BODY

2

EXPANDER

3

708-25-15120

PISTON

4

708-25-15130

SEAT

5

708-25-25130

SPRING

6

708-25-55250

SPRING

7

708-23-15120

SEAT

8

708-23-15160

PLUG

9

07000-B2018

O-RING

10

708-25-15150

COVER

11

01580-10806

NUT

12

708-25-15320

BOLT

13

01602-20619

WASHER

14

708-25-15171

PLUG

15

07002-62034

O-RING

16

07239-12009

NUT

17

708-25-15180

SLEEVE

18

708-25-15280

SPOOL

19

708-25-15310

SPRING

20

708-25-15330

SPACER

21

708-25-15430

PLUG

22

708-25-15340

SCREW

23

07000-B2012

O-RING

24

708-25-15250

COVER

25

01580-10806

NUT

26

708-25-15320

BOLT

27

01602-20619

WASHER

28

708-25-15260

PLUG

29

07002-60823

O-RING

30

708-25-15270

ARM

31

708-25-15360

PIN

32

708-25-15370

WASHER

33

708-25-15380

E-RING

34

07040-11007

PLUG

35

07002-61023

O-RING

36

708-25-55110

PLATE

37

07000-B2011

O-RING

38

01010-80825

BOLT

39

708-2L-25480

FILTER

Выбрано товаров: 45
