Запчасти Komatsu PC1250SP-8R ОСНОВН. НАСОС (/)(NO. НАСОС) Y

|$1

708-2L-00691

PUMP ASS'Y

|$2

708-2L-00690

PUMP ASS'Y

|$3

THIS ASSEMBLY CONSISTS OF ALL PARTS

|$4

SHOWN IN FIGS.Y1600-21A0 TO Y1600-31A0.

|$5

708-2L-01690

PUMP SUB ASS'Y

1

708-2L-22430

SHAFT,FRONT

2

708-2L-32150

BEARING

3

708-2E-05040

WASHER KIT

|$9

WASHER,3.1MM

|$10

WASHER,3.0MM

|$11

WASHER,2.9MM

|$12

WASHER,2.8MM

4

708-25-12790

RING,SNAP

5

708-25-52861

SEAL,OIL

6

708-25-12812

HOUSING

7

07000-A2080

O-RING

8

708-25-05130

SHIM KIT

|$18

SHIM,0.2MM

|$19

SHIM,0.1MM

9

01010-80820

BOLT

10

01643-30823

WASHER

|$22

708-2L-04151

BLOCK ASS'Y,REAR

11

BLOCK,CYLINDER

12

PLATE,VALVE

13

720-68-19610

PIN

14

04065-04818

RING,SNAP

15

708-2L-23131

SEAT

16

708-2L-33160

SPRING

17

708-7L-13140

SEAT

18

708-2L-23351

GUIDE,RETAINER

19

708-2L-23360

PIN

20

708-2L-33340

RETAINER,SHOE

21

708-2L-33310

PISTON SUB ASS'Y
