Запчасти Komatsu PC1250SP-8R ОСНОВН. НАСОС (/)(NO. НАСОС) Y

|$1

708-2L-00681

PUMP ASS'Y

|$2

708-2L-00680

PUMP ASS'Y

|$3

THIS ASSEMBLY CONSISTS OF ALL PARTS

|$4

SHOWN IN FIGS.Y1600-01A0 TO Y1600-16A0.

|$5

705-11-23040

PUMP ASS'Y

1

705-17-01010

BRACKET ASS'Y

|$7

705-17-01030

BRACKET

2

705-17-01350

PLANE BEARING

3

705-17-23010

CASE.GEAR

4

705-17-01120

COVER ASS'Y

|$11

705-17-01160

COVER

5

705-17-01350

PLANE BEARING

6

705-17-23410

GEAR.DRIVE

7

705-17-23510

GEAR.DRIVEN

8

705-17-01610

PLATE

9

705-67-01470

SEAL.RING

10

705-67-01440

RING.BACK-UP

11

705-67-01380

O-RING

12

04020-00820

PIN.DOWEL

13

01252-61280

BOLT

14

01643-51232

WASHER

15

07430-71360

SEAL.OIL

16

705-17-01870

PLATE

17

04065-03515

RING.SNAP
