Запчасти Komatsu PC1250SP-8R ОСНОВН. НАСОС (/)(NO. НАСОС) Y

Схема запчастей Komatsu PC1250SP-8R - ОСНОВН. НАСОС (/)(NO. НАСОС) Y
28
7
29
6
35
36
38
37
33
34
4
32
31
3
32
5
14
15
13
16
8
8
2
17
18
1
20
27
19
2
2
26
10
25
23
9
21
12
22
11
24
29
36
30
28
35

Артикул

Название

Примечание

Количество

|$1

708-2L-00681

PUMP ASS'Y

|$2

708-2L-00680

PUMP ASS'Y

|$3

THIS ASSEMBLY CONSISTS OF ALL PARTS

|$4

SHOWN IN FIGS.Y1600-01A0 TO Y1600-16A0.

|$5

708-25-85260

SERVO VALVE ASS'Y, REAR

|$6

708-25-09681

VALVE ASS'Y,CO+NC

|$7

708-23-00441

BODY ASS'Y

1

BODY

2

EXPANDER

3

708-25-17460

PLUG

4

708-25-17430

SCREW

5

07000-B2010

O-RING

6

708-25-17131

COVER

7

01580-10806

NUT

8

708-25-17141

SPOOL

9

708-25-17150

SLEEVE

10

708-25-17160

PISTON

11

708-25-17170

COVER

12

07000-B2014

O-RING

13

708-25-17180

SEAT

14

708-25-17690

SPRING

15

708-25-17220

PISTON

16

708-25-17370

SEAT

17

708-25-17250

SPRING

18

708-25-17470

SEAT

19

708-23-17290

COVER

20

07000-B3028

O-RING

21

708-25-17380

PLUG

22

708-25-15340

SCREW

23

07000-B2021

O-RING

24

708-23-17240

COVER

25

708-25-17480

PISTON

26

01252-60630

BOLT

27

01602-20619

WASHER

28

01252-60616

BOLT

29

01602-20619

WASHER

30

01580-10806

NUT

31

07000-B2012

O-RING

32

07001-02012

RING,BACK-UP

33

708-25-17451

SLEEVE

34

07000-B2012

O-RING

35

01252-60616

BOLT

36

01602-20619

WASHER

37

07000-B2021

O-RING

38

07001-02021

RING.BACK-UP

Выбрано товаров: 45
