КОВШ .7M. 8MM (ГОРИЗОНТАЛЬН. ПАЛЕЦ)

Запчасти Komatsu PC1250SP-8R КОВШ .7M. 8MM (ГОРИЗОНТАЛЬН. ПАЛЕЦ) T

Схема запчастей Komatsu PC1250SP-8R - КОВШ .7M. 8MM (ГОРИЗОНТАЛЬН. ПАЛЕЦ) T
26
4
27
15
18
3
29
20
30
13
28
21
4
33
11
12
19
23
16
25
32
24
16
23
1
31
6
5
9
2
7
8
22
17
10
14
9
8
7
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

1

21N-93-94811

BUCKET

2

21N-70-34410

PLATE (WELDED)

3

21N-70-37711

ADAPTER (WELDED)

4

21N-70-41241

ADAPTER (WELDED)

5

21N-93-93N30

PLATE (WELDED)

6

21N-93-93N40

PLATE (WELDED)

7

21N-93-94350

PLATE (WELDED)

8

21N-93-94360

PLATE (WELDED)

9

21N-93-94370

PLATE (WELDED)

10

21N-93-94380

PLATE (WELDED)

|$11

21N-93-94380

PLATE (WELDED)

11

21N-93-94820

PLATE (WELDED)

12

21N-93-94831

PLATE, L.H.(L.H) (WELDED)

13

21N-93-94841

PLATE, R.H. (WELDED)

14

21N-93-94870

PLATE (WELDED)

15

21N-93-94891

SHROUD (WELDED)

16

21N-93-94C90

PLATE (WELDED)

17

21N-93-94D10

PLATE (WELDED)

18

21N-93-94E20

PLATE (WELDED)

19

21N-93-94E30

PLATE (WELDED)

20

21N-93-94E40

PLATE (WELDED)

21

21N-93-94E50

PLATE (WELDED)

22

21N-93-94E60

PLATE (WELDED)

23

21N-93-94E70

PLATE (WELDED)

24

21N-93-94E80

PLATE (WELDED)

25

21N-93-94E90

PLATE (WELDED)

26

21N-70-37721

TOOTH

27

21N-70-37731

PIN

28

21N-70-14310

COVER

29

01010-83085

BOLT

30

01643-33080

WASHER

31

21N-70-34180

BUSHING

32

21N-70-14220

BUSHING

33

21N-70-00060

SHIM ASS'Y

|$35

SHIM,1.0MM

|$36

SHIM,0.5MM
