Запчасти Komatsu PC1250SP-8R МЕХАНИЗМ ПОВОРОТА (ПЕРЕДН.) N

1

706-7K-01230

MOTOR ASS'Y

|$2

706-7K-01140

MOTOR ASS'Y

|$3

706-7K-01111

MOTOR ASS'Y

2

207-26-71240

RING

3

07040-11209

PLUG

4

07002-11223

O-RING

5

21N-26-33170

GAUGE

6

21N-26-33150

FILLER

7

07030-00252

BREATHER

8

07049-01012

PLUG

9

01010-81240

BOLT

10

01643-31232

WASHER

11

21N-26-33190

CASE

12

07049-02430

PLUG

13

06000-23124

BEARING

14

21N-26-31140

BEARING

15

21N-26-31110

SHAFT,13 TEETH

16

208-26-61291

OIL SEAL

17

21N-26-33230

COVER

18

01010-81030

BOLT

19

01643-31032

WASHER

20

07000-15390

O-RING

21

208-26-71181

CARRIER

22

208-26-71140

GEAR

23

207-27-61230

BEARING

24

20Y-27-21250

THRUST WASHER

25

207-27-61250

PIN

26

20Y-27-21290

PIN

27

208-26-71230

PLATE

28

205-32-51211

BOLT

29

208-26-71151

GEAR

30

01010-81645

BOLT

31

01643-31645

WASHER

32

208-26-71130

GEAR

33

208-26-71241

PLATE

34

208-26-71170

CARRIER

35

207-26-71520

GEAR

36

22U-26-21320

BEARING

37

22U-26-21240

WASHER,THRUST

38

207-26-71210

PIN

39

04064-04018

SNAP RING

40

208-26-71210

HOLDER

41

04260-01270

BALL

42

207-26-71510

GEAR

43

207-26-71261

PLATE

44

07730-40004

VALVE
