Запчасти Komatsu PC1250SP-8R ЛЕВ. КРЫШКА(ЗАДН. ) M

1

21N-54-39414

FRAME

2

20Y-54-28170

BRACKET

3

01010-81230

BOLT

4

01643-31232

WASHER

5

205-54-51971

DOVE TAIL

|$6

205-54-51970

DOVE TAIL

6

01010-80616

BOLT

7

01643-30623

WASHER

8

209-54-63260

BRACKET

9

01010-81230

BOLT

10

01643-31232

WASHER

11

21N-54-43110

COVER

|$13

21N-54-41560

COVER

12

20Y-54-28161

HINGE, WELDED

13

21N-54-31390

SHEET

14

21N-54-31760

SHEET

15

21N-54-43130

SHEET~

|$18

21N-54-41580

SHEET

16

205-54-53550

DOVE TAIL

17

01010-80616

BOLT

18

01643-30623

WASHER

19

205-54-64140

BAR

20

04050-13018

PIN

21

20B-54-12210

SPRING

22

01023-10408

SCREW

23

01010-81230

BOLT

24

01643-31232

WASHER

25

198-54-55990

LOCK

26

01580-10806

NUT

27

01643-30823

WASHER

28

21N-54-43120

COVER

|$32

21N-54-41570

COVER

29

20Y-54-28161

HINGE

30

21N-54-31760

SHEET

31

21N-54-43140

SHEET~

|$36

21N-54-41590

SHEET

32

205-54-64140

BAR

33

04050-13018

PIN

34

20B-54-12210

SPRING

35

01023-10408

SCREW

36

01010-81230

BOLT

37

01643-31232

WASHER

38

01010-81230

BOLT

39

01643-31232

WASHER
