Запчасти Komatsu PC1250SP-8R ОСНОВН. КОНСТРУКЦИЯ (КОНСОЛЬ)(ПРАВ.) K

1

22U-43-23111

PLATE

2

21N-06-41140

WIRING HARNESS

3

22U-43-23120

BRACKET

4

22U-43-23130

BRACKET

5

207-06-71180

SWITCH, M/P-UP

6

208-43-71690

COVER

7

22U-06-22420

POTENTIOMETER ASS'Y

8

22U-06-22470

KNOB

9

08086-20000

SWITCH

10

22U-06-22480

PLATE

11

21N-06-33291

SWITCH ASS'Y

12

22U-06-22290

SWITCH, SWING

13

22U-06-22390

SWITCH, LIGHT

14

20Y-06-23770

CLIP

15

20Y-06-23920

CLAMP

16

08034-10414

BAND

17

01023-60408

SCREW

18

01023-60512

SCREW

19

01023-10508

SCREW

20

01023-10512

SCREW

21

01601-20513

WASHER

22

01023-60625

SCREW

23

01640-20610

WASHER

24

208-43-71610

CUSHION

25

208-43-71620

PIPE

26

01023-70514

SCREW

27

22U-43-23210

COVER

|$28

20Y-06-31320

SWITCH ASS'Y

28

20Y-06-31330

HARNESS

29

PLATE

30

208-43-71420

CAP

31

22U-43-23230

COVER

32

208-43-71670

FRAME, R.H

33

22U-43-23250

SEAT

34

22U-43-23260

CLIP

35

01023-60616

SCREW

36

569-06-61960

RELAY

37

287-06-16420

BRACKET

38

01435-00612

BOLT

39

01023-60410

SCREW

40

22U-43-23711

COVER

41

01023-10614

SCREW

42

01643-30623

WASHER

43

21N-43-41150

SHEET

44

21N-43-41210

SHEET
