Запчасти Komatsu PC1250SP-8R ВОЗВРАТНАЯ ЛИНИЯ(ПОВОРОТН. ВСАСЫВ.)(/) H

1

21N-62-37320

TUBE

2

07000-B3048

O-RING

3

07372-21240

BOLT

4

01643-51232

WASHER

5

07000-B3045

O-RING

6

01010-81275

BOLT

7

01643-31232

WASHER

8

21N-62-42170

BLOCK

9

01010-81235

BOLT

10

175-54-34170

WASHER

11

21N-62-42370

BRACKET

12

01010-81235

BOLT

13

175-54-34170

WASHER

14

21N-62-41491

HOSE

|$15

21N-62-41490

HOSE

15

07000-B3032

O-RING

16

07371-31049

FLANGE

17

07372-21035

BOLT

18

01643-51032

WASHER

19

21N-62-41480

HOSE

|$21

21N-62-41481

HOSE

|$22

21N-62-41480

HOSE

20

07000-B3032

O-RING

21

07371-31049

FLANGE

22

07372-21035

BOLT

23

01643-51032

WASHER

24

07094-11024

CLAMP

25

07095-01035

CUSHION

26

01010-81280

BOLT

27

01643-31232

WASHER

28

21N-62-41420

BRACKET

29

01010-81235

BOLT

30

01643-31232

WASHER

31

07094-11024

CLAMP

32

07095-01035

CUSHION

33

01010-81280

BOLT

34

01643-31232

WASHER

35

07094-11024

CLAMP

36

07095-01035

CUSHION

37

01011-81205

BOLT

38

01643-31232

WASHER

39

195-33-11220

SPACER
