Запчасти Komatsu PC1250SP-8R ТОПЛИВН. БАК. (С БЫСТР. ЗАПРАВ.) D

1

21N-04-41511

TANK

|$2

22U-04-21241

STRAINER ASS'Y

|$3

22U-04-21200

FLOAT ASS'Y

2

22U-04-21210

GUIDE

3

20Y-04-21580

CAP

4

22U-04-21220

FLOAT

5

07056-18425

STRAINER

6

17A-04-41411

CAP

7

21N-04-41212

FLANGE

8

01010-81235

BOLT

9

01643-31232

WASHER

10

07000-15200

O-RING

11

7861-93-5810

SENSOR

12

07000-13050

O-RING

13

01010-80612

BOLT

14

01643-30623

WASHER

15

17A-04-42150

ADAPTER

16

195-04-31160

COVER

17

07000-12115

O-RING

18

01010-80820

BOLT

19

01602-20825

WASHER

|$22

22U-60-21520

BREATHER

20

421-60-35170

ELEMENT

21

COVER

22

NUT

23

BODY

24

VALVE ASS'Y

25

O-RING

26

CASE

27

209-04-42150

UNION

28

02896-11015

O-RING

29

21N-04-41232

UNION

30

02896-11018

O-RING

31

07700-40460

VALVE

32

07700-40661

VALVE

33

21N-64-36520

ELBOW

34

02896-11012

O-RING

35

21N-54-41191

COVER

36

01010-81230

BOLT

37

175-54-34170

WASHER

38

21N-54-42551

BRACKET

39

01010-81225

BOLT

40

175-54-34170

WASHER

41

21N-54-39990

STEP

42

01010-81230

BOLT
