Запчасти Komatsu PC1250SP-8R ТОПЛИВН. БАК. D

1

21N-04-41112

TANK

|$2

22U-04-21241

STRAINER ASS'Y

|$3

22U-04-21200

FLOAT ASS'Y

2

22U-04-21210

GUIDE

3

20Y-04-21580

CAP

4

22U-04-21220

FLOAT

5

07056-18425

STRAINER

6

17A-04-41411

CAP

7

21N-04-41212

FLANGE

8

01010-81235

BOLT

9

01643-31232

WASHER

10

07000-15200

O-RING

11

7861-93-5810

SENSOR

12

07000-13050

O-RING

13

01010-80612

BOLT

14

01643-30623

WASHER

|$17

22U-60-21520

BREATHER

15

421-60-35170

ELEMENT

16

421-60-35180

COVER

17

421-60-35190

NUT

18

BODY

19

VALVE ASS'Y

20

O-RING

21

CASE

22

209-04-42150

UNION

23

02896-11015

O-RING

24

21N-04-41232

UNION

25

02896-11018

O-RING

26

07700-40460

VALVE

27

07700-40661

VALVE

28

21N-64-36520

ELBOW

29

02896-11012

O-RING

30

21N-54-41191

COVER

31

01010-81230

BOLT

32

175-54-34170

WASHER

33

21N-54-42551

BRACKET

34

01010-81225

BOLT

35

175-54-34170

WASHER

36

21N-54-39990

STEP

37

01010-81230

BOLT

38

01643-31232

WASHER

39

02782-10422

ELBOW

40

07002-12034

O-RING

41

02896-11012

O-RING

42

21N-04-41410

BOLT
