Запчасти Komatsu PC1250SP-8R ОХЛАЖД-Е (ВЕНТИЛЯТОР КРЕПЛЕНИЕ) (МОТОР ВЕНТИЛЯТОРА ТРУБЫ) C

1

21N-03-41830

TUBE

2

02896-61018

O-RING

3

02782-1062A

ELBOW

4

02896-61018

O-RING

5

07002-62434

O-RING

6

07094-10518

CLAMP

7

07095-00526

CUSHION

8

01010-81275

BOLT

9

01643-31232

WASHER

10

209-03-41860

BRACKET

11

209-03-41870

COVER

12

01010-81035

BOLT

13

01643-31032

WASHER

14

21N-03-41840

TUBE

15

02896-61018

O-RING

16

21N-62-41391

ELBOW

17

11Y-62-12440

NIPPLE

18

02896-61018

O-RING

19

07002-62434

O-RING

20

07094-10518

CLAMP

21

07095-00526

CUSHION

22

01010-81275

BOLT

23

01643-31232

WASHER

24

21N-03-41850

TUBE

25

02896-61012

O-RING

26

02782-10516

ELBOW

27

02896-61015

O-RING

28

07002-62034

O-RING

29

07094-10417

CLAMP

30

07095-00420

CUSHION

31

01010-81275

BOLT

32

01643-31232

WASHER

33

21N-03-41920

BRACKET

34

21N-03-41930

COVER

35

01010-81065

BOLT

36

01643-31032

WASHER

37

21N-03-41942

COVER

|$38

21N-03-41941

COVER

38

21T-03-32750

SHEET

39

21T-03-32770

SHEET

40

01010-81230

BOLT

41

01643-31232

WASHER

42

21M-06-21190

WIRING HARNESS

43

04434-51012

CLIP

44

01010-81225

BOLT
