Запчасти Komatsu PC1250SP-8R ВОЗДУХОВОД И СЛИВН. ТРУБКА A

1

6245-11-4360

TUBE, AIR

2

07283-31087

CLIP

3

01643-31232

WASHER

4

01597-01211

NUT

5

6245-11-4331

BRACKET

6

01435-01025

BOLT

7

6245-11-4390

SEAT

8

01010-81025

BOLT

9

01643-31032

WASHER

10

6212-11-4410

HOSE

11

6162-14-4750

CLAMP

12

6245-11-4240

BRACKET

13

01435-01025

BOLT

14

6245-11-4370

PLATE

15

01010-81235

BOLT

16

01643-31232

WASHER

17

01010-81240

BOLT

18

01643-31232

WASHER

19

426-06-11570

BRACKET

20

07283-31087

CLIP

21

01643-31232

WASHER

22

01597-01211

NUT

23

6218-11-4971

SEAT

24

6261-81-2700

SENSOR ASS'Y, BOOST PRESSURE

|$25

6261-81-2710

SENSOR

|$26

6261-81-2720

O-RING

25

01435-00614

BOLT

26

6245-71-5580

BLOCK

27

07000-A2021

O-RING

28

07042-A0108

PLUG

29

01435-01055

BOLT

30

01435-01065

BOLT

31

6245-71-6290

BRACKET

32

6560-61-7300

SENSOR ASS'Y, BOOST TEMPERATURE

|$35

6560-61-7310

SENSOR

|$36

6735-21-1930

O-RING

33

6261-81-6901

SENSOR ASS'Y, FUEL TEMPERATURE

|$38

6216-84-9740

SEAL

34

6245-71-5390

TUBE, SPILL

35

07206-30812

BOLT, JOINT

36

07005-01212

GASKET

37

6210-51-8320

CLIP

38

01010-81020

BOLT

39

01643-31032

WASHER
