Запчасти Komatsu PC1250SP-8R ГЕНЕРАТОР (AMP)(ВНУТР. ЧАСТИ)(7-UP) A

|$1

600-861-6111

ALTERNATOR, 60AMP

1

KD0-35100-0418

ROTOR ASS'Y

2

KD0-35943-0240

COLLAR

3

KD0-35923-0160

COLLAR

4

KD0-09201-0980

BEARING, BALL

5

KD0-35200-0528

STATOR ASS'Y

6

KD0-35300-0450

BRACKET ASS'Y

7

KD0-09201-1450

BEARING

8

KD0-35926-0070

RETAINER

9

KD0-35951-0060

PACKING

10

KD0-35926-0090

RETAINER

11

KD1-33926-0730

RETAINER

12

KD0-0275-06802

BOLT

13

KD0-35411-0648

PULLEY

14

KD0-35421-0240

FAN

15

KD0-09006-0730

NUT

16

KD0-35120-0528

COIL, FIELD

|$18

KD0-35700-1140

BRACKET ASS'Y

17

KD0-35710-1330

BRACKET

18

KD0-35730-0700

RECTIFIER ASS'Y

19

KD0-09170-2501

CONDENSER

20

KD0-35943-0170

BUSHING

21

KD0-35943-0154

BUSHING

22

KD0-35923-0134

COLLAR

23

KD0-35943-0160

BUSHING

24

KD0-35943-0140

BUSHING

25

KD0-35784-0210

BAR

26

KD0-35784-0290

BAR, PLATE

27

KD0-09057-0220

WASHER

28

KD0-0055-05202

SCREW

29

KD0-0055-05122

SCREW

30

KD0-09011-3540

SCREW

31

KD0-0056-05302

SCREW

32

KD0-35719-0201

REGULATOR ASS'Y

33

KD0-35761-0308

COVER

34

KD0-35902-0010

NUT

35

KD0-09006-0370

NUT

36

KD0-33902-0080

NUT

37

KD0-33902-0090

NUT

38

KD0-0056-05302

SCREW

39

KD0-09011-3540

SCREW
