Запчасти Komatsu PC1250SP-8R ГЕНЕРАТОР (AMP)(ВНУТР. ЧАСТИ)(9-7) A

|$1

600-861-6111

ALTERNATOR ASS'Y, 60AMP

|$2

600-861-6110

ALTERNATOR ASS'Y, 60AMP

1

KD0-35100-0300

ROTOR ASS'Y

2

KD1-33923-0790

COLLAR

3

KD1-35923-0160

COLLAR

4

KD0-09201-0980

BEARING,BALL

5

KD0-35200-0460

STATOR ASS'Y

6

KD0-35300-0350

FRONT BRACKET ASS'Y

7

KD0-09201-1140

BEARING,BALL

8

KD0-35926-0070

RETAINER

9

KD0-35951-0060

PACKING

10

KD0-35926-0090

RETAINER

11

KD1-33926-0730

RETAINER

12

KD0-0275-06802

BOLT

13

KD0-35411-0640

PULLEY

14

KD0-35421-0240

FAN

15

KD1-0330-16012

WASHER, PLAIN

16

KD1-0335-16002

WASHER, SPRING

17

KD0-0280-16022

NUT

18

KD0-35120-0290

FIELD COIL

|$21

KD0-35700-0950

REAR BRACKET ASS'Y

19

KD0-35710-1150

BRACKET,REAR

20

KD0-35730-0700

RECTIFIER ASS'Y

21

KD0-09170-2501

CONDENSER

22

KD0-35943-0150

BUSHING,INSULATE

23

KD0-35923-0130

COLLAR

24

KD0-35943-0160

BUSHING,INSULATE

25

KD0-35943-0140

BUSHING,INSULATE

26

KD0-35943-0170

BUSHING,INSULATE

27

KD0-35784-0210

BAR,CONNECT

28

KD0-35784-0290

BAR,PLATE

29

KD0-09057-0220

WASHER

30

KD0-35719-0211

REGULATOR ASS'Y

31

KD0-35761-0250

COVER
