Запчасти Komatsu PC1250SP-8R БОКОВ. КРЫШКА ПРАВ., (/) (№-) БОКОВ. КРЫШКА ПРАВ., EXTREME HOT AREA СПЕЦ-ЯIFICATION ( DEG C)

1

21N-54-41311

Frame

2

21N-53-31420

Sheet

3

21N-53-31430

Sheet

4

22U-54-24180

Bar

5

21N-54-41331

Cover

6

01010-81230

Bolt

7

01643-31232

Washer

8

21N-54-41321

Duct

9

21K-54-22460

Hinge,Welded

10

01010-81230

Bolt

11

01643-31232

Washer

12

01010-81240

Bolt

13

01643-31232

Washer

14

21N-54-41340

Net

15

01010-80816

Bolt

16

01643-30823

Washer

17

21N-54-41811

Duct

18

21N-53-31180

Sheet

19

21N-53-31190

Sheet

20

21N-53-31230

Sheet

21

21N-54-41840

Sheet

22

21N-54-41890

Sheet

23

01010-81240

Bolt

24

01643-31232

Washer

25

21N-54-43170

Cover

26

21K-54-22460

Hinge,Welded

27

01010-81235

Bolt

28

01643-31232

Washer

29

195-Z11-2970

Cap

30

21N-54-41880

Seal

31

21N-54-41830

Net

32

01010-80816

Bolt

33

01643-30823

Washer

34

20Y-54-29232

Bar

35

20B-54-12210

Spring

36

01023-10408

Screw

37

01010-81230

Bolt

38

01643-31232

Washer

39

01010-81250

Bolt

40

01643-31232

Washer

41

01010-81230

Bolt

42

124-54-26540

Washer
