Запчасти Komatsu PC1250SP-8R NO. НАСОС, ВНУТР. ЧАСТИ (/) (№-) NO. НАСОС

Схема запчастей Komatsu PC1250SP-8R - NO. НАСОС, ВНУТР. ЧАСТИ (/) (№-) NO. НАСОС
21
9
10
6
7
8
5
4
3
2
1
12
14
17
16
15
11
19
18
20
13

Артикул

Название

Примечание

Количество

|$0

708-2L-00691

Pump Assembly

|$1

708-2L-00690

Pump Assembly

|$2

708-2L-01690

Pump Subassembly

1

708-2L-22430

Shaft,Front

2

708-2L-32150

Bearing

3

708-2E-05040

Washer Kit

3

Washer, T=3.1mm

3

Washer, T=3.0mm

3

Washer, T=2.9mm

3

Washer, T=2.8mm

4

708-25-12790

Ring, Snap

5

708-25-52861

Seal, Oil

6

708-25-12812

Housing

7

07000-A2080

O-ring

8

708-25-05130

Shim Kit

8

Shim, T=0.2mm

8

Shim, T=0.1mm

9

01010-80820

Bolt

10

01643-30823

Washer

|$19

708-2L-04151

Block Assembly,Rear

11

Block, Cylinder

12

Plate

13

720-68-19610

Pin

14

04065-04818

Ring, Snap

15

708-2L-23131

Seat

16

708-2L-33160

Spring

17

708-7L-13140

Seat

18

708-2L-23351

Guide, Retainer, Retainer

19

708-2L-23360

Pin

20

708-2L-33340

Retainer, Shoe

21

708-2L-33310

Piston Subassembly

Выбрано товаров: 31
