Запчасти Komatsu PC1250SP-8R УПРАВЛЯЮЩ. КЛАПАН, NO. (/) (№-) УПРАВЛЯЮЩ. КЛАПАН

|$0

709-14-94001

Valve Assembly, Control

|$1

709-10-91501

Valve Assembly

1

Body

2

Spool

3

709-10-91210

Sleeve

4

709-10-91220

Piston

5

709-10-91230

Spring

6

709-10-91240

Flange

7

01010-81030

Bolt

8

01602-21030

Washer

9

07000-02055

O-ring

10

07000-13048

O-ring

11

07000-13040

O-ring

12

709-10-91350

Sleeve

13

706-73-70140

Valve, Check

14

706-73-70150

Spring

15

709-74-92450

Plug

16

709-74-92460

Nut

17

700-93-11320

O-ring

18

700-93-11330

Ring, Back-up

19

07000-12010

O-ring

20

07001-02010

Ring, Back-up

21

01011-61425

Bolt

22

01011-81215

Bolt

23

01011-81250

Bolt

24

01643-31445

Washer, Flat

25

01643-31232

Washer

26

709-10-91131

Plug

27

07000-13035

O-ring

28

07001-03035

Ring, Back-up

29

07000-13030

O-ring

30

07001-03030

Ring, Back-up

31

709-10-91140

Plate

32

01010-80835

Bolt
