Запчасти Komatsu PC1250SP-8R НАСОС СМАЗКИ, ВНУТР. ЧАСТИ (/) (№-) НАСОС СМАЗКИ

|$0

209-68-11202

Pump Assembly, Grease

|$1

209-68-11212

Pump

1

YU708523-4

Pipe

2

YU708311-4

Case

3

YU701811-4

Nut

4

YU701815-4

Washer

5

YU770180-4

Packing

6

YU701810-4

Washer

7

YU706066-4

Housing, Gland

8

YU701766-4

Nipple, Tube

9

YU701768-4

Elbow

10

YU701765-4

Sleeve

11

YU706067-4

Bushing

12

YU706068-4

Spindle

13

YU640012-0

O-ring

14

YU770182-4

O-ring

15

YU640132-0

O-ring

16

YU704893-4

Piston

17

YU701825-4

Spring

18

YU770563-4

Cap

19

YU705661-4

Arm

20

YU705659-4

Bushing

21

YU706069-3

Body

21

YU681-170

Silencer

22

YU702725-4

Washer

23

YU770287-4

Packing

24

YU702726-4

Holder

25

YU702727-4

Spring

26

YU702734-4

Seat

27

YU702582-4

Washer

28

YU701823-4

Block

29

YU701816-4

Holder

30

YU681768-4

Screw

31

YU701818-4

Plate, Guide

32

YU701822-4

Seat

33

YU770181-4

Packing

34

YU702971-4

Pin

35

YU706091-4

Union

36

YU709042-4

Tube

37

YU709043-4

Rod

38

YU702975-4

Union

39

YU702974-4

Washer

40

YU702976-4

Spring

41

YU630313-0

Ball

42

YU702977-4

Washer

43

YU801051-4

Cylinder Assembly

44

YU706399-4

Rod, Plunger

45

YU706072-4

Tube, Foot

46

YU702980-4

Plate

47

YU702981-4

Valve, Foot

48

YU702982-4

Seat

49

YU830407-4

Adapter Assembly, Valve

50

YU709597-4

Tube

51

YU770409-4

Packing

52

YU709644-4

Tube

53

YU702984-4

Plate

54

YU627010-4

Nut

55

YU632019-1

Pin

56

YU632754-4

Pin
