Запчасти Komatsu PC1250SP-8R КОВШ (№-) КОВШ, .7M, 8MM ШИР., WEAR ПЛАСТИНА, KMAX TOOTH, THRUST ADJUSTMENT, БОКОРЕЗЫ

Схема запчастей Komatsu PC1250SP-8R - КОВШ (№-) КОВШ, .7M, 8MM ШИР., WEAR ПЛАСТИНА, KMAX TOOTH, THRUST ADJUSTMENT, БОКОРЕЗЫ
8
18
7
29
30
28
31
19
11
19
25
24
13
18
10
8
2
2
20
20
14
27
26
12
15
21
15
6
3
22
16
17
4
9
1
23
5

Артикул

Название

Примечание

Количество

1

21N-939-4811

Bucket

2

21N-939-4C90

Plate,Welded

3

21N-939-4E20

Plate,Welded

4

21N-939-4E30

Plate,Welded

5

21N-939-4E40

Plate,Welded

6

21N-939-4E50

Plate,Welded

7

21N-939-4E60

Plate,Welded

8

21N-939-4E70

Plate,Welded

9

21N-939-4E80

Plate,Welded

10

21N-939-4E90

Plate,Welded

11

21N-939-4D10

Plate,Welded

12

21N-939-4891

Shroud,Welded

13

21N-70-34410

Plate,Welded

14

21N-70-37711

Adapter,Welded

15

21N-70-41241

Adapter,Welded

16

21N-939-3N30

Plate,Welded

17

21N-939-3N40

Plate,Welded

18

21N-939-4350

Plate,Welded

19

21N-939-4360

Plate,Welded

20

21N-939-4370

Plate,Welded

21

21N-939-4820

Plate,Welded

22

21N-939-4831

Plate,Welded

23

21N-939-4841

Plate,Welded

24

21N-939-4870

Plate,Welded

25

21N-939-4380

Plate,Welded

26

21N-70-37721

Tooth

27

21N-70-37731

Pin Assembly

28

21N-70-14310

Cover

29

01010-83085

Bolt

30

01643-33080

Washer

31

21N-70-34180

Bushing

Выбрано товаров: 31
