Запчасти Komatsu PC1250SP-8R МЕХАНИЗМ ПОВОРОТА И МОТОР, ЗАДН. (№-) МЕХАНИЗМ ПОВОРОТА И МОТОР

1

207-26-71240

Ring

2

21N-26-33210

Gauge

3

21N-26-33220

Filler

4

07287-01012

Hose

5

07285-00130

Clip

6

208-871-5170

Joint

7

07002-11223

O-ring

8

07030-00252

Breather

9

08034-40521

Band

10

208-871-5161

Bracket

11

07283-32738

Clip, Pipe

12

01597-01009

Nut

13

01643-31032

Washer

14

01010-81030

Bolt

15

01643-31032

Washer

16

01010-81240

Bolt

17

01643-31232

Washer

18

21N-26-33190

Case

19

07049-02430

Plug

20

06000-23124

Bearing

21

21N-26-31140

Bearing

22

21N-26-31110

Shaft, 13 Teeth

23

208-26-61291

Seal, Oil

24

21N-26-33230

Cover

25

01010-81030

Bolt

26

01643-31032

Washer

27

07000-15390

O-ring

28

208-26-71181

Carrier

29

208-26-71140

Gear

30

207-27-61230

Bearing

31

20Y-27-21250

Washer, Thrust

32

207-27-61250

Pin

33

20Y-27-21290

Pin

34

208-26-71230

Plate

35

205-32-51211

Bolt

36

208-26-71151

Gear

37

01010-81645

Bolt

38

01643-31645

Washer

39

208-26-71130

Gear

40

208-26-71241

Plate

41

208-26-71170

Carrier

42

207-26-71520

Gear

43

22U-26-21320

Bearing

44

22U-26-21240

Washer

45

207-26-71210

Pin

46

04064-04018

Ring, Snap

47

208-26-71210

Holder

48

04260-01270

Ball

49

207-26-71510

Gear

50

207-26-71261

Plate

51

07730-40004

Valve, Drain

52

07270-21590

Tube

53

07281-00197

Clamp

54

208-26-71380

O-ring

55

01010-82485

Bolt

56

01643-32460

Washer

57

07000-15335

O-ring
