Запчасти Komatsu PC1250SP-8R ЦИЛИНДР СТРЕЛЫ(ДЛЯ ЭКСКАВАТ.)(№-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G1

707-01-XZ502

CYLINDER GROUP,L.H. (FINAL COATING)

G2

707-01-XZ512

CYLINDER GROUP,R.H. (FINAL COATING)

|$5

21N-63-02304

CYLINDER ASS'Y

1

21N-63-52342

CYLINDER

2

21N-63-52321

ROD,PISTON

3

707-46-14010

BUSHING

4

21T-72-15860

BUSHING

5

21T-72-15870

SEAL,DUST (KIT)

6

07043-00108

PLUG

7

707-46-14010

BUSHING

8

21T-72-15860

BUSHING

9

21T-72-15870

SEAL,DUST (KIT)

10

07043-00108

PLUG

11

707-71-31820

COLLAR

12

707-71-11750

RING

13

07000-15220

O-RING (KIT)

14

07001-05220

RING,BACK-UP (KIT)

15

707-71-51750

PLUNGER

16

707-28-22710

HEAD,CYLINDER

17

566-63-22241

SEAL,DUST (KIT)

18

07179-14180

RING,SNAP

19

707-51-16030

PACKING,ROD (KIT)

20

707-51-16640

RING,BUFFER (KIT)

21

707-52-91350

BUSHING

22

07000-15220

O-RING (KIT)

23

707-35-92300

RING,BACK-UP

24

01011-83010

BOLT

25

01643-33080

WASHER

26

707-36-22300

PISTON

27

707-44-22280

RING,PISTON (KIT)

28

707-39-22820

RING,WEAR (KIT)

29

707-44-22920

RING

30

707-40-22870

SPACER

31

01252-61670

BOLT

32

07000-15135

O-RING (KIT)

33

707-35-91440

RING,BACK-UP (KIT)

34

21N-63-52371

TUBE,L.H.

34

21N-63-52471

TUBE,R.H.

35

07000-13038

O-RING (KIT)

36

21N-63-52380

TUBE,L.H.

36

21N-63-52480

TUBE,R.H.

37

07000-13048

O-RING (KIT)

38

707-88-28570

BRACKET

39

21N-62-18440

BAND

40

707-88-28850

SEAT

41

707-88-28860

SEAT

42

01010-81240

BOLT

43

01643-31232

WASHER

44

01010-81245

BOLT

45

01643-31232

WASHER

46

01010-81450

BOLT

47

01643-31445

WASHER

48

07000-13048

O-RING

49

07378-11410

HEAD

50

01010-81455

BOLT

51

07371-51470

FLANGE

52

07000-13038

O-RING

53

07378-11210

HEAD

54

01010-81460

BOLT

55

07371-51260

FLANGE

K

707-99-78740

SERVICE KIT
