Запчасти Komatsu PC1250SP-8 NO. НАСОС, ВНУТР. ЧАСТИ (/) (№8-) NO. НАСОС

Схема запчастей Komatsu PC1250SP-8 - NO. НАСОС, ВНУТР. ЧАСТИ (/) (№8-) NO. НАСОС
23
3
5
6
30
8
9
12
13
14
15
31
8
32
33
39
24
21
40
20
28
35
7
36
4
28
25
22
27
11
17
18
34
29
16
34
29
33
1
26
35
2
10
2
29
19
38
37

Артикул

Название

Примечание

Количество

|$0

708-2H-00440

Pump Assembly

|$1

708-27-09121

Valve Assembly, Servo,Front

|$2

708-27-09521

Valve Assembly, CO+NC

|$3

708-23-00430

Body Assembly

1

Body

2

Expander

3

708-25-17460

Plug

4

708-25-17430

Screw

5

07000-B2010

O-ring

6

708-25-17131

Cover

7

01580-10806

Nut

8

708-25-17141

Spool

9

708-25-17150

Sleeve

10

708-25-17160

Piston

11

708-25-17170

Cover

12

07000-B2014

O-ring

13

708-25-17180

Seat

14

708-25-17690

Spring

15

708-25-17451

Sleeve

16

708-25-17220

Piston

17

708-25-17370

Seat

18

708-25-17250

Spring

19

708-25-17470

Seat

20

708-25-17480

Piston

21

708-25-17380

Plug

22

07000-B3028

O-ring

23

07000-B2021

O-ring

24

708-23-17240

Cover

25

708-23-17290

Cover

26

708-25-15340

Screw

27

706-75-40310

Bolt

28

708-25-15320

Bolt

29

01602-20619

Washer

30

01580-10806

Nut

31

07000-B2012

O-ring

32

07000-B2012

O-ring

33

07001-02012

Ring, Back-up

34

708-25-15320

Bolt

35

01602-20619

Washer

36

07000-B2021

O-ring

37

07001-02021

Ring, Back-up

38

07040-11007

Plug

39

07002-61023

O-ring

40

708-25-17390

Plate

Выбрано товаров: 44
