Запчасти Komatsu PC1250SP-8 АВТОМАТИЧ.-СИСТ. СМАЗКИ СИСТЕМА, ОСНОВН. ТРУБЫ (№8-) АВТОМАТИЧ.-СИСТ. СМАЗКИ СИСТЕМА, С MM РУКОЯТЬ

1

21T-68-72450

Hose

2

07086-00411

Hose, Taper Seal Type

3

04434-52512

Clip

4

21N-68-37560

Tube

5

203-973-5660

Clamp

6

203-973-5720

Seat

7

01010-81055

Bolt

8

01643-31032

Washer

9

07086-004A4

Hose, Taper Seal Type

10

07238-10424

Connector

11

21N-68-37570

Block

12

01010-81030

Bolt

13

01643-31032

Washer

14

23S-44-34140

Elbow

15

195-04-12280

Elbow

16

07086-00416

Hose, Taper Seal Type

17

04434-52511

Clip

18

01010-81020

Bolt

19

01643-31032

Washer

20

566-01-61190

Elbow

21

561-95-37450

Injector Assembly

22

581-96-19590

Plug

23

01010-81050

Bolt

24

01643-31032

Washer

25

561-95-63250

Elbow

26

21N-68-32460

Hose

27

425-S95-2140

Sleeve

28

425-S95-2160

Hose Stud

29

425-S95-1280

Hose

30

425-S95-2140

Sleeve

31

425-S95-2160

Hose Stud

32

561-95-63310

Connector

33

07086-004A3

Hose, Taper Seal Type

34

07086-004A9

Hose, Taper Seal Type
