Запчасти Komatsu PC1250SP-7 ВЫПУСКН. (TROPICAL WEATHER СПЕЦ-Я.) КОМПОНЕНТЫ ДВИГАТЕЛЯ

1

6162-13-5280

PIPE,EX

2

6162-14-5640

CAP

3

01010-81235

BOLT

4

01643-31232

WASHER

5

6240-11-6100

MUFFLER

6

01010-E1285

BOLT

7

6142-22-4640

SPACER

8

01580-11210

NUT

9

01643-31232

WASHER

10

6240-11-5751

FLANGE

10

6240-11-5750

FLANGE

11

6240-11-5760

GASKET

12

01020-11035

BOLT

12

01020-11030

BOLT

13

01643-31032

WASHER

14

6240-11-5741

JOINT

14

6240-11-5740

JOINT

15

6240-11-5510

TUBE

16

6162-13-5660

CLAMP

17

6152-11-4970

SPACER

18

01435-01035

BOLT

19

01584-01008

NUT

20

6204-81-9560

SPACER

21

01435-01080

BOLT

22

07260-20990

HOSE

22

07261-20990

HOSE

23

07285-00150

CLIP

24

04434-51612

CLIP

25

01010-81225

BOLT

26

01643-31232

WASHER

27

6240-11-7380

COVER

28

01010-E1020

BOLT

29

01643-31032

WASHER

30

08672-01000

INDICATOR

31

21N-01-37220

BRACKET

32

01010-81230

BOLT

33

01643-31232

WASHER

34

08671-50060

HOSE

35

7861-93-1420

SENSOR

36

08037-02512

GROMMET

37

08193-21012

CLIP

38

01010-81225

BOLT

39

01643-31232

WASHER

40

07261-25814

HOSE

41

07289-00070

CLAMP

42

281-03-11710

CLIP

43

01010-81225

BOLT

44

01643-31232

WASHER
