Запчасти Komatsu PC1250SE-7 ОСНОВН. КЛАПАН (/) (4-Х СЕКЦИОНН.) (NO.) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|1

709-14-94001

CONTROL VALVE

|1

709-14-94000

CONTROL VALVE

|1

709-10-91501

VALVE ASS'Y

1

BODY

2

SPOOL

3

709-10-91210

SLEEVE

4

709-10-91220

PISTON

5

709-10-91230

SPRING

6

709-10-91240

FLANGE

7

01010-81030

BOLT

8

01602-21030

WASHER

9

07000-02055

O-RING

10

07000-13048

O-RING

11

07000-13040

O-RING

12

709-10-91350

SLEEVE

13

706-73-70140

VALVE,CHECK

14

706-73-70150

SPRING

15

709-74-92450

PLUG

16

709-74-92460

NUT

17

700-93-11320

O-RING

18

700-93-11330

RING,BACK-UP

19

07000-12010

O-RING

20

07001-02010

RING

21

01011-61425

BOLT

22

01011-81215

BOLT

23

01011-81250

BOLT

24

01643-31445

WASHER

25

01643-31232

WASHER

26

709-10-91131

PLUG

27

07000-13035

O-RING

28

07001-03035

RING,BACK-UP

29

07000-13030

O-RING

30

07001-03030

RING

31

709-10-91140

PLATE

32

01010-80835

BOLT
