Запчасти Komatsu PC1250LC-8 ЦИЛИНДР КОВША, (№8-) ЦИЛИНДР КОВША, ДЛЯ 7MM РУКОЯТЬ

|$0

21N-63-02371

Cylinder Assembly

1

21N-63-72940

Cylinder

2

21N-63-72920

Rod, Piston

3

707-46-13010

Bushing

4

07043-00108

Plug, Taper

5

707-46-14010

Bushing

6

21T-72-15860

Bushing

7

21T-72-15870

Seal, Dust, (Kit : K11)

8

07043-00108

Plug, Taper

9

707-71-51471

Plunger

10

707-71-31460

Collar

11

707-71-11450

Ring

12

707-28-20330

Head, Cylinder

13

707-56-14740

Seal, Dust, (Kit : K11)

14

07179-14160

Ring, Snap

15

707-51-14080

Packing, Rod, (Kit : K11)

16

707-51-14640

Ring, Buffer, (Kit : K11)

17

707-52-91151

Bushing

18

07000-15195

O-ring, (Kit : K11)

19

707-35-92050

Ring, Back-up, (Kit : K11)

20

07001-05195

Ring, Back-up, (Kit : K11)

21

01011-82705

Bolt

22

01643-32780

Washer

23

707-36-20300

Piston

24

707-44-20180

Ring, Piston, (Kit : K11)

25

707-39-20820

Ring, Wear, (Kit : K11)

26

707-44-20910

Ring

27

707-40-20870

Spacer

28

01252-61460

Bolt

29

07000-12115

O-ring, (Kit : K11)

30

707-35-52860

Ring, Back-up, (Kit : K11)

31

21N-63-72970

Tube

32

21N-63-72980

Tube

33

21N-63-72960

Bracket

34

21N-63-72990

Bracket

35

707-88-96110

Band

36

07283-34346

Clip

37

01599-01011

Nut

38

01643-31032

Washer

39

01010-81240

Bolt

40

01643-51232

Washer

41

176-61-41330

Clamp

42

01010-81250

Bolt

43

01643-31232

Washer

44

01010-81450

Bolt

45

01643-31445

Washer, Flat

46

07000-13048

O-ring, (Kit : K11)

47

01010-81280

Bolt

48

07000-13038

O-ring, (Kit : K11)

49

07378-11410

Head

50

07371-51470

Flange, Split

51

01010-81455

Bolt
