Запчасти Komatsu PC1250LC-8 БОКОВ. КРЫШКА ПРАВ., (/) (№8-) БОКОВ. КРЫШКА ПРАВ., ЕС НОВ. NOISE ARRANGEMENT

1

21N-54-41311

Frame

2

21N-53-31420

Sheet

3

21N-53-31430

Sheet

4

22U-54-24180

Bar

5

21N-54-41331

Cover

6

01010-81230

Bolt

7

01643-31232

Washer

8

21N-54-41321

Duct

9

21K-54-22460

Hinge,Welded

10

01010-81230

Bolt

11

01643-31232

Washer

12

01010-81240

Bolt

13

01643-31232

Washer

14

21N-54-41340

Net

15

01010-80816

Bolt

16

01643-30823

Washer

17

21N-54-41811

Duct

18

21N-53-31180

Sheet

19

21N-53-31190

Sheet

20

21N-53-31230

Sheet

21

21N-54-41840

Sheet

22

21N-54-41890

Sheet

23

01010-81240

Bolt

24

01643-31232

Washer

25

21N-54-41821

Cover

26

21K-54-22460

Hinge,Welded

27

21N-53-31350

Sheet

28

01010-81235

Bolt

29

01643-31232

Washer

30

195-Z11-2970

Cap

31

21N-54-41880

Seal

32

21N-54-41851

Blade

33

21N-54-41871

Sheet

34

01010-81020

Bolt

35

01643-31032

Washer

36

21N-54-41860

Frame

37

01010-80616

Bolt

38

01643-30623

Washer

39

21N-54-41830

Net

40

01010-80816

Bolt

41

01643-30823

Washer

42

20Y-54-29232

Bar

43

20B-54-12210

Spring

44

01023-10408

Screw

45

01010-81230

Bolt

46

01643-31232

Washer

47

01010-81250

Bolt

48

01643-31232

Washer

49

01010-81230

Bolt

50

124-54-26540

Washer
