Запчасти Komatsu PC1250LC-8 ПРОПОРЦИОНАЛЬН. PRESSURE УПРАВЛ-Е (PPC) ТРУБЫ СОЕД-Е, ШЛАНГИ, ДЕКА (№8-) ПРОПОРЦИОНАЛЬН. PRESSURE УПРАВЛ-Е (PPC) ТРУБЫ СОЕД-Е, С 7MM РУКОЯТЬ

1

02760-00324

Hose, Face Seal Type

2

02760-00326

Hose, Face Seal Type

3

20Y-62-22790

Band, Red

4

20Y-62-22820

Band, Blue

5

20Y-62-22850

Band, Green

6

23S-61-24870

Clip

7

01010-81225

Bolt

8

01643-31232

Washer

9

02760-00314

Hose, Face Seal Type

10

02760-00319

Hose, Face Seal Type

11

02760-00315

Hose, Face Seal Type

12

20Y-62-22810

Band, Yellow

13

20Y-62-22840

Band, Black

14

20Y-62-22860

Band, Brown

15

02760-00317

Hose

16

02760-00318

Hose, Face Seal Type

17

20Y-62-22790

Band, Red

18

20Y-62-22830

Band, White

19

20Y-62-22850

Band, Green

20

04434-53412

Clip

21

01010-81225

Bolt

22

01643-31232

Washer

23

02760-00310

Hose, Face Seal Type

24

02760-00318

Hose, Face Seal Type

25

02760-00319

Hose, Face Seal Type

26

20Y-62-22790

Band, Red

27

20Y-62-22810

Band, Yellow

28

20Y-62-22820

Band, Blue

29

20Y-62-22830

Band, White

30

20Y-62-22850

Band, Green

31

04435-51512

Clip

32

01010-81225

Bolt

33

01643-31232

Washer

34

21N-62-36580

Bracket

35

01010-81225

Bolt

36

01643-31232

Washer

37

20Y-62-15951

Clip
