Запчасти Komatsu PC1250LC-8 ДРЕНАЖН. ТРУБЫ, МОТОР ПОВОРОТА ФИЛЬТР. (№89-) ДРЕНАЖН. ТРУБЫ

1

02763-00204

Hose, Face Seal Type

2

02896-11008

O-ring

3

20Y-62-43460

Nipple

4

07002-12034

O-ring

5

21N-62-42471

Bracket

6

01010-81025

Bolt

7

01643-31032

Washer

7

20Y-62-51681

Filter Assembly

8

Head

9

Valve Assembly

10

Case

11

20Y-62-51691

Element

12

706-76-71390

O-ring

13

01010-81075

Bolt

14

01643-31032

Washer

15

21X-62-21140

Elbow

16

07002-12034

O-ring

17

17A-04-41331

Connector

18

07002-12034

O-ring

19

14X-04-21620

Valve

20

07002-12034

O-ring

21

02782-10214

Elbow

22

07002-12034

O-ring

23

02763-00205

Hose

24

02896-11008

O-ring

25

02762-00215

Hose, Face Seal Type

26

20Y-62-22820

Band, Blue

27

02896-11008

O-ring

27

20Y-62-51681

Filter Assembly

28

Head

29

Valve Assembly

30

Case

31

20Y-62-51691

Element

32

706-76-71390

O-ring

33

01010-81075

Bolt

34

01643-31032

Washer

35

02782-10214

Elbow

36

07002-12034

O-ring

37

02763-00214

Hose, Face Seal Type

38

02896-11008

O-ring

39

04435-51412

Clip

40

01010-81225

Bolt

41

01643-31232

Washer

42

21N-54-41222

Frame

|$44

21N-54-41222

Frame

43

21N-54-42991

Frame

|$46

21N-54-42411

Frame
