Запчасти Komatsu PC1250LC-8 NO. НАСОС, ВНУТР. ЧАСТИ (7/) (№8-) NO. НАСОС

|$0

708-2L-00691

Pump Assembly

|$1

708-2L-00690

Pump Assembly

|$2

708-25-09191

Valve Assembly, Servo,Front

|$3

708-25-00840

Body Assembly

1

Body

2

Expander

3

708-25-15120

Piston

4

708-25-15130

Seat

5

708-25-25130

Spring

6

708-25-55250

Spring

7

708-23-15120

Seat

8

708-23-15160

Plug

9

07000-B2018

O-ring

10

708-25-15150

Cover

11

01580-10806

Nut

12

708-25-15320

Bolt

13

01602-20619

Washer

14

708-25-15171

Plug

15

07002-62034

O-ring

16

07239-12009

Nut

17

708-25-15180

Sleeve

18

708-25-15280

Spool

19

708-25-15310

Spring

20

708-25-15330

Spacer

21

708-25-15430

Plug

22

708-25-15340

Screw

23

07000-B2012

O-ring

24

708-25-15250

Cover

25

01580-10806

Nut

26

708-25-15320

Bolt

27

01602-20619

Washer

28

708-25-15260

Plug

29

07002-60823

O-ring

30

708-25-15270

Arm

31

708-25-15360

Pin

32

708-25-15370

Washer

33

708-25-15380

E-ring

34

07040-11007

Plug

35

07002-61023

O-ring

36

708-25-55110

Plate

37

07000-B2011

O-ring

38

01010-80825

Bolt

39

708-2L-25480

Filter

40

708-2L-25490

O-ring

41

07000-B1009

O-ring

42

708-25-19230

Orifice

43

708-25-19250

Plug

44

01643-50823

Washer

45

07000-B3048

O-ring

46

708-2L-25480

Filter
