Запчасти Komatsu PC1250LC-8 NO. НАСОС, ВНУТР. ЧАСТИ (/) (№9-) NO. НАСОС

|$0

708-2L-00681

Pump Assembly

|$1

708-2L-01680

Pump Subassembly

|$2

708-2L-04960

Case Assembly,Rear

1

Case,Rear

2

Plug

3

07044-12412

Plug

4

07002-62434

O-ring

5

708-2L-21970

Cap, End

6

708-2L-32260

Bearing

7

07000-B2135

O-ring

8

6130-21-1910

Pin, Dowel

9

07000-B2012

O-ring

10

708-2L-41270

Ring, Back-up

11

07000-B1009

O-ring

12

07000-B5165

O-ring

13

07000-B3032

O-ring

14

01252-61080

Bolt, Hexagon Socket Head

15

04530-11018

Bolt, Eye

16

708-25-13630

Ring

17

708-2L-22450

Shaft,Rear

18

708-2L-32150

Bearing

19

708-2E-05040

Washer Kit

19

Washer, T=3.1mm

19

Washer, T=3.0mm

19

Washer, T=2.9mm

19

Washer, T=2.8mm

20

708-25-12790

Ring, Snap

21

708-25-05021

Shim Kit

21

Shim, T=0.5mm

21

Shim, T=0.2mm

21

Shim, T=0.15mm

21

Shim, T=0.1mm

22

708-25-12950

Plate

23

01252-61040

Bolt, Hexagon Socket Head

24

01643-31032

Washer

25

01252-31016

Bolt

26

708-25-05130

Shim Kit

26

Shim, T=0.2mm

26

Shim, T=0.1mm
