Запчасти Komatsu PC1250LC-8 ОСНОВН. НАСОС (7/) (N. НАСОС)(№-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|$1

708-2L-00690

PUMP ASS'Y

|$3

708-25-09191

SERVO VALVE ASS'Y,FRONT

|$4

708-25-00840

BODY ASS'Y

1

BODY

2

EXPANDER

3

708-25-15120

PISTON

4

708-25-15130

SEAT

5

708-25-25130

SPRING

6

708-25-55250

SPRING

7

708-23-15120

SEAT

8

708-23-15160

PLUG

9

07000-B2018

O-RING

10

708-25-15150

COVER

11

01580-10806

NUT

12

708-25-15320

BOLT

13

01602-20619

WASHER

14

708-25-15171

PLUG

15

07002-62034

O-RING

16

07239-12009

NUT

17

708-25-15180

SLEEVE

18

708-25-15280

SPOOL

19

708-25-15310

SPRING

20

708-25-15330

SPACER

21

708-25-15430

PLUG

22

708-25-15340

SCREW

23

07000-B2012

O-RING

24

708-25-15250

COVER

25

01580-10806

NUT

26

708-25-15320

BOLT

27

01602-20619

WASHER

28

708-25-15260

PLUG

29

07002-60823

O-RING

30

708-25-15270

ARM

31

708-25-15360

PIN

32

708-25-15370

WASHER

33

708-25-15380

E-RING

34

07040-11007

PLUG

35

07002-61023

O-RING

36

708-25-55110

PLATE

37

07000-B2011

O-RING

38

01010-80825

BOLT

39

708-2L-25480

FILTER

40

708-2L-25490

O-RING

41

07000-B1009

O-RING

42

708-25-19230

ORIFICE

43

708-25-19250

PLUG

44

01643-50823

WASHER

45

07000-B3048

O-RING

46

708-2L-25480

FILTER
