Запчасти Komatsu PC1250LC-8 ЛЕВ. СТУПЕНИ (HANDRAIL)(№-) РАЗНОЕ

1

21N-53-32151

HAND RAIL

2

21N-53-31952

BRACKET

2

21N-53-31951

BRACKET

3

21N-53-32142

BRACKET

3

21N-53-32141

BRACKET

4

07283-32738

CLIP

5

07283-52737

SEAT

6

01597-01009

NUT

7

01643-71032

WASHER

8

21N-53-32160

HAND RAIL

9

01010-81230

BOLT

10

01643-31232

WASHER

11

01010-81645

BOLT

12

01643-31645

WASHER

13

21N-53-31931

HAND RAIL

14

21N-53-31952

BRACKET

14

21N-53-31951

BRACKET

15

21N-53-31972

BRACKET

15

21N-53-31971

BRACKET

16

07283-32738

CLIP

17

07283-52737

SEAT

18

01597-01009

NUT

19

01643-71032

WASHER

20

21N-53-31940

HAND RAIL

21

01010-81230

BOLT

22

01643-31232

WASHER

23

01010-81645

BOLT

24

01643-31645

WASHER

25

21N-53-31922

PIPE

26

21N-53-31952

BRACKET

26

21N-53-31951

BRACKET

27

21N-53-31962

BRACKET

27

21N-53-31961

BRACKET

28

21N-53-32412

BRACKET

28

21N-53-32411

BRACKET

29

07283-32738

CLIP

30

07283-52737

SEAT

31

01597-01009

NUT

32

01643-71032

WASHER

33

01010-81645

BOLT

34

01643-31645

WASHER

35

21N-53-32420

BRACKET

36

08037-01610

GROMMET

37

01010-D1225

BOLT

38

01643-71232

WASHER

39

8285-54-1570

CHAIN
