Запчасти Komatsu PC1250LC-8 МЕХАНИЗМ ПОВОРОТА (ЗАДН.)(№-) ПОВОРОТН. КРУГ И КОМПОНЕНТЫ

1

706-7K-01110

MOTOR ASS'Y

2

207-26-71240

RING

3

21N-26-33210

GAUGE

4

21N-26-33220

FILLER

5

07287-01012

HOSE

6

07285-00130

CLIP

7

208-871-5170

JOINT

8

07002-11223

O-RING

9

07030-00252

BREATHER

10

08034-40521

BAND

11

208-871-5161

BRACKET

12

07283-32738

CLIP

13

01597-01009

NUT

14

01643-31032

WASHER

15

01010-81030

BOLT

16

01643-31032

WASHER

17

01010-81240

BOLT

18

01643-31232

WASHER

19

21N-26-33190

CASE

20

07049-02430

PLUG

21

06000-23124

BEARING

22

21N-26-31140

BEARING

23

21N-26-31110

SHAFT, 13 TEETH

24

208-26-61291

OIL SEAL

25

21N-26-33230

COVER

26

01010-81030

BOLT

27

01643-31032

WASHER

28

07000-15390

O-RING

29

208-26-71181

CARRIER

30

208-26-71140

GEAR

31

207-27-61230

BEARING

32

20Y-27-21250

WASHER

33

207-27-61250

PIN

34

20Y-27-21290

PIN

35

208-26-71230

PLATE

36

205-32-51211

BOLT

37

208-26-71151

GEAR

38

01010-81645

BOLT

39

01643-31645

WASHER

40

208-26-71130

GEAR

41

208-26-71241

PLATE

42

208-26-71170

CARRIER

43

207-26-71520

GEAR

44

22U-26-21320

BEARING

45

22U-26-21240

WASHER

46

207-26-71210

PIN

47

04064-04018

RING

48

208-26-71210

HOLDER

49

04260-01270

BALL

50

207-26-71510

GEAR

51

207-26-71261

PLATE

52

07730-40004

VALVE

53

07270-21590

TUBE

54

07281-00197

CLAMP

55

208-26-71380

O-RING

56

01010-82485

BOLT

57

01643-32460

WASHER

58

07000-15335

O-RING
