Запчасти Komatsu PC1250-8R КАБИНА, ЛАМПА РАБОЧ. ОСВЕЩЕНИЯ (№-) КАБИНА

1

01643-30623

Washer

2

01023-20412

Screw

3

21N-06-41211

Wiring Harness

4

21N-54-38290

Wiring Harness

5

20Y-54-52470

Grommet

6

20Y-54-36150

Grommet

7

08034-00414

Band

8

08037-12536

Grommet

9

08059-00413

Clip

10

08910-10000

Speaker

11

01023-10412

Screw

12

01010-81020

Bolt

13

01643-31032

Washer

14

04434-52310

Clip

15

08037-02512

Grommet

16

21N-06-11860

Wiring Harness

17

08034-20519

Band

18

20Y-54-39511

Nozzle

19

01370-40412

Screw

20

17M-911-2670

Hose

21

08037-01008

Grommet

22

21N-54-38820

Working Lamp Assembly

|$22

421-06-23330

Bulb, 70watt

23

01010-D1016

Bolt

24

01643-71032

Washer

25

21N-06-11880

Bracket

26

20Y-06-21551

Bracket

27

20Y-06-21590

Bracket

28

01010-81225

Bolt

29

01643-31232

Washer

30

21T-06-33980

Working Lamp Assembly

|$31

21T-06-33970

Bulb, 24/42watt

31

01010-81225

Bolt

32

01643-31232

Washer

33

209-53-14430

Working Lamp Assembly

|$35

421-06-23330

Bulb, 70watt

34

01010-D1016

Bolt

35

01643-71032

Washer

36

21N-54-38411

Plate

37

175-06-81610

Grommet

38

01435-40616

Bolt
