Запчасти Komatsu PC1250-8R НИЖН. ГИДРОЦИЛИНДР КОВША, ПРАВ. (№-) НИЖН. ГИДРОЦИЛИНДР КОВША, ДЛЯ ПРЯМАЯ ЛОПАТА CONFIGURATION

|$0

707-01-0E940

Cylinder Assembly

1

707-13-16820

Cylinder

2

707-58-11460

Rod, Piston

3

707-76-10130

Bushing

4

07145-00100

Seal, Dust, (Kit : K16)

5

07043-00108

Plug, Taper

6

707-76-10130

Bushing

7

07145-00100

Seal, Dust, (Kit : K16)

8

07043-00108

Plug, Taper

9

707-71-32810

Collar

10

707-35-91640

Ring, Back-up, (Kit : K16)

11

07000-15150

O-ring, (Kit : K16)

12

707-71-61130

Plunger

13

707-27-16920

Head, Cylinder

14

07179-13126

Ring, Snap

15

707-56-11740

Seal, Dust, (Kit : K16)

16

707-51-11030

Packing, Rod, (Kit : K16)

17

707-51-11640

Ring, Buffer, (Kit : K16)

18

707-52-90851

Bushing

19

07000-15150

O-ring, (Kit : K16)

20

707-35-91640

Ring, Back-up, (Kit : K16)

21

01010-82085

Bolt

22

707-88-75310

Washer

23

707-36-16580

Piston

24

707-44-16180

Ring, Piston, (Kit : K16)

25

707-39-16120

Ring, Wear, (Kit : K16)

26

707-44-16910

Ring

27

07000-15100

O-ring, (Kit : K16)

28

07001-05100

Ring, Back-up, (Kit : K16)

29

01310-01216

Screw

30

707-86-12250

Tube

31

707-86-12270

Tube

32

707-88-25060

Bracket

33

707-88-22510

Bracket

34

707-88-21380

Band

35

07282-03411

Clamp

36

01435-01020

Bolt

37

01435-01235

Bolt

38

01435-01055

Bolt

39

07000-13035

O-ring, (Kit : K16)

40

07371-31049

Flange, Split

41

707-88-33040

Cap

42

07372-21035

Bolt

43

01643-51032

Washer
