Запчасти Komatsu PC1250-8R ТОПЛИВН. БАК. (№-) ТОПЛИВН. БАК.

1

21N-04-41112

Tank

|$1

22U-04-21241

Strainer Assembly

|$2

22U-04-21200

Float Assembly

2

22U-04-21210

Guide

3

20Y-04-21580

Cap

4

22U-04-21220

Float

5

07056-18425

Strainer

6

17A-04-41411

Cap

7

21N-04-41212

Flange

8

01010-81235

Bolt

9

01643-31232

Washer

10

07000-15200

O-ring

11

7861-93-5810

Sensor

12

07000-13050

O-ring

13

01010-80612

Bolt

14

01643-30623

Washer

15

22U-60-21520

Breather

16

209-04-42150

Union

17

02896-11015

O-ring

18

21N-04-41232

Union

19

02896-11018

O-ring

20

07700-40460

Valve, Fuel Drain

21

07700-40661

Valve, Fuel Drain

22

21N-64-36520

Elbow

23

02896-11012

O-ring

24

21N-54-41191

Cover

25

01010-81230

Bolt

26

175-54-34170

Washer

27

21N-54-42551

Bracket

28

01010-81225

Bolt

29

175-54-34170

Washer

30

21N-54-39990

Step

31

01010-81230

Bolt

32

01643-31232

Washer

33

02782-10422

Elbow

34

07002-12034

O-ring

35

02896-11012

O-ring

36

21N-04-41410

Bolt

37

01643-32460

Washer

38

21N-04-41290

Plate

39

01011-82015

Bolt

40

01643-32060

Washer

41

21N-04-41241

Plate

42

21N-04-41261

Sheet

43

21N-04-41271

Sheet

44

21N-04-41281

Sheet

45

09460-00000

Padlock
