Запчасти Komatsu PC1250-8R ЦИЛИНДР КОВША, (№7-) ЦИЛИНДР КОВША, ДЛЯ 7MM РУКОЯТЬ

|$0

707-F1-01400

Cylinder Assembly

1

21N-63-72940

Cylinder

2

21N-63-72920

Rod, Piston

3

707-46-13010

Bushing

4

07043-00108

Plug, Taper

5

707-46-14010

Bushing

6

21T-72-15860

Bushing

7

21T-72-15870

Seal, Dust, (Kit : K12)

8

07043-00108

Plug, Taper

9

707-71-51471

Plunger

10

707-71-31460

Collar

11

707-71-11450

Ring

12

707-28-20331

Head, Cylinder

13

707-56-14740

Seal, Dust, (Kit : K12)

14

07179-14160

Ring, Snap

15

707-51-14870

Packing, Rod, (Kit : K12)

16

707-51-14650

Ring, Buffer, (Kit : K12)

17

707-52-91151

Bushing

18

07000-15195

O-ring, (Kit : K12)

19

707-35-92050

Ring, Back-up, (Kit : K12)

20

707-75-14110

Ring, Snap

21

07001-05195

Ring, Back-up, (Kit : K12)

22

01011-82705

Bolt

23

01643-32780

Washer

24

707-36-20300

Piston

25

707-44-20150

Ring, Piston, (Kit : K12)

26

707-39-20020

Ring, Wear, (Kit : K12)

27

707-44-20910

Ring

28

707-40-20870

Spacer

29

01252-61460

Bolt

30

07000-B2115

O-ring, (Kit : K12)

31

707-35-52860

Ring, Back-up, (Kit : K12)

32

21N-63-72970

Tube

33

21N-63-72980

Tube

34

21N-63-72960

Bracket

35

21N-63-72990

Bracket

36

707-88-96110

Band

37

07283-34346

Clip

38

01597-01009

Nut

39

01643-31032

Washer

40

07372-21240

Bolt

41

01643-51232

Washer

42

176-61-41330

Clamp

43

01010-81255

Bolt

44

01643-31232

Washer

45

01010-81450

Bolt

46

01643-31445

Washer, Flat

47

01010-81280

Bolt

48

01643-31232

Washer

49

07000-13038

O-ring, (Kit : K12)

50

07371-51470

Flange, Split

51

01010-81455

Bolt

52

07000-13048

O-ring, (Kit : K12)

53

707-88-33060

Cap
