Запчасти Komatsu PC1250-8R МЕХАНИЗМ ПОВОРОТА И МОТОР (№-) МЕХАНИЗМ ПОВОРОТА И МОТОР, ПОДАЮЩ. ONLY

|$0

21N-26-00110

Swing Machinery Assembly

1

21N-26-33190

Case

2

07049-02430

Plug

3

06000-23124

Bearing

4

21N-26-31140

Bearing

5

21N-26-31110

Shaft

6

208-26-61291

Seal, Oil

7

21N-26-33230

Cover

8

01010-81030

Bolt

9

01643-31032

Washer

10

07000-15390

O-ring

11

208-26-71181

Carrier

12

208-26-71140

Gear

13

207-27-61230

Bearing

14

20Y-27-21250

Washer, Thrust

15

207-27-61250

Pin

16

20Y-27-21290

Pin

17

208-26-71230

Plate

18

205-32-51211

Bolt

19

208-26-71151

Gear

20

01010-81645

Bolt

21

01643-31645

Washer

22

208-26-71130

Gear

23

208-26-71241

Plate

24

208-26-71170

Carrier

25

207-26-71520

Gear

26

22U-26-21320

Bearing

27

22U-26-21240

Washer

28

207-26-71210

Pin

29

04064-04018

Ring, Snap

30

208-26-71210

Holder

31

04260-01270

Ball

32

207-26-71510

Gear

33

207-26-71261

Plate

34

207-26-71610

Cover

35

01010-81240

Bolt

36

01643-31232

Washer

37

07042-30617

Plug, Taper

38

07042-30108

Plug
