Запчасти Komatsu PC1250-8R ЦИЛИНДР РУКОЯТИ(FR LADER)(№-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G-1

707-01-XZ550

CYLINDER GROUP,L.H. (FINAL COATING)

G-2

707-01-XZ560

CYLINDER GROUP,R.H. (FINAL COATING)

|$5

21N-63-03121

CYLINDER ASS'Y

1

21N-63-66340

CYLINDER

2

21N-63-66320

ROD,PISTON

3

707-46-11510

BUSHING

4

07043-00108

PLUG

5

707-46-11510

BUSHING

6

07043-00108

PLUG

7

707-71-51860

PLUNGER

8

04260-01270

BALL

9

707-71-91510

CAP

10

707-27-18970

HEAD,CYLINDER

11

07179-14146

RING,SNAP

12

707-56-13520

SEAL,DUST (KIT)

13

707-52-91070

BUSHING

14

707-51-13030

PACKING,ROD (KIT)

15

707-51-13630

RING,BUFFER (KIT)

16

07000-15175

O-RING (KIT)

17

707-35-91840

RING,BACK-UP (KIT)

18

01011-82400

BOLT

19

707-88-75410

WASHER

20

707-36-18600

PISTON

21

707-44-18280

RING,PISTON (KIT)

22

707-39-18830

RING,WEAR (KIT)

23

707-44-18920

RING

24

07000-15120

O-RING (KIT)

25

07001-05120

RING,BACK-UP (KIT)

26

01310-01225

SCREW

27

21N-63-66370

TUBE,L.H.

27

21N-63-66470

TUBE,R.H.

28

21N-62-13241

TUBE

29

01435-01055

BOLT

30

07000-13035

O-RING (KIT)

31

01010-81450

BOLT

32

01643-31445

WASHER

33

07000-13048

O-RING (KIT)

34

21N-63-66390

BRACKET

35

707-88-21090

BAND

36

01010-81240

BOLT

37

01643-31232

WASHER

38

07283-23442

CLIP

39

01599-01011

NUT

40

01643-31032

WASHER

41

07282-04311

CLAMP

42

01010-81020

BOLT

43

07378-11210

HEAD

44

07371-51260

FLANGE

45

07000-13038

O-RING

46

01010-81245

BOLT

47

07378-11410

HEAD

48

07371-51470

FLANGE

49

01010-81455

BOLT

K

707-99-69670

SERVICE KIT
