Запчасти Komatsu PC1250-8R НИЖН. ГИДРОЦИЛИНДР КОВША (ДЛЯ ПОГРУЗ.)(№-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G-1

707-01-XU330

CYLINDER GROUP,L.H. (FINAL COATING)

G-2

707-01-XU340

CYLINDER GROUP,R.H. (FINAL COATING)

|$5

707-01-0E940

CYLINDER ASS'Y

1

707-13-16820

CYLINDER

2

707-76-10130

BUSHING

3

07145-00100

SEAL,DUST (KIT)

4

07043-00108

PLUG,GREASE

5

707-27-16920

HEAD,CYLINDER

6

707-51-11030

PACKING,ROD (KIT)

7

707-51-11640

RING,BUFFER (KIT)

8

707-52-90850

BUSHING

9

198-63-94170

SEAL,DUST (KIT)

10

07179-13126

RING,SNAP

11

707-71-32810

COLLAR

12

07000-15150

O-RING (KIT)

13

707-35-91640

RING,BACK-UP (KIT)

14

01010-82085

BOLT

15

707-88-75310

WASHER

16

707-58-11460

ROD,PISTON

17

707-76-10130

BUSHING

18

07145-00100

SEAL,DUST (KIT)

19

07043-00108

PLUG,GREASE

20

707-36-16580

PISTON

21

07000-15100

O-RING (KIT)

22

07001-05100

RING,BACK-UP (KIT)

23

707-44-16910

RING

24

707-39-16120

RING,WEAR (KIT)

25

707-44-16180

RING,PISTON (KIT)

26

707-71-61130

PLUNGER

27

01310-01216

SCREW

28

707-86-12240

TUBE,L.H.

28

707-86-12250

TUBE,R.H.

29

707-86-12260

TUBE,L.H.

29

707-86-12270

TUBE,R.H.

30

07000-13035

O-RING (KIT)

31

01435-01055

BOLT

32

707-88-25060

BRACKET

33

707-88-22510

BRACKET

34

707-88-21380

BAND

35

01435-01235

BOLT

36

07282-03411

CLAMP

37

01435-01020

BOLT

38

707-88-33040

CAP

39

07371-31049

FLANGE

40

07372-21035

BOLT

41

01643-51032

WASHER

K

707-99-67090

SERVICE KIT
