Запчасти Komatsu PC1250-8R ЦИЛИНДР РУКОЯТИ(FR ЭКСКАВАТ.)(№-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

Схема запчастей Komatsu PC1250-8R - ЦИЛИНДР РУКОЯТИ(FR ЭКСКАВАТ.)(№-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ
1
2
3
3
4
5
6
7
8
9
10
11
12
13
14
14
15
16
17
18
19
20
21
21
22
22
23
24
24
25
26
26
27
27
28
28
28
29
30
31
32
33
34
35
36
37
38
39
40
41
41
42
42
43
43
44
44
45
45
46
46
47
47
48
49
50
51
52
52
53
53
54
54
55
55
56
56
57

Артикул

Название

Примечание

Количество

G

707-01-XMC00

CYLINDER GROUP,(FINAL COATING)

G

707-01-XZ522

CYLINDER GROUP,(FINAL COATING)

|$5

707-01-0CA50

CYLINDER ASS'Y

|$6

21N-63-02324

CYLINDER ASS'Y

1

707-13-25210

CYLINDER

1

21N-63-62341

CYLINDER

2

707-76-16030

BUSHING

3

707-77-16020

SEAL,DUST (KIT)

4

07043-00108

PLUG

5

707-28-25840

HEAD,CYLINDER

6

707-51-17030

PACKING,ROD (KIT)

7

707-51-17640

RING,BUFFER (KIT)

8

707-52-91451

BUSHING

9

707-56-17510

SEAL,DUST (KIT)

10

07179-15190

RING,SNAP

11

07000-15250

O-RING (KIT)

12

707-35-92600

RING,BACK-UP (KIT)

13

07000-15250

O-RING (KIT)

14

07001-05250

RING,BACK-UP (KIT)

15

707-71-31830

COLLAR

16

707-71-11850

RING

17

01011-83330

BOLT

18

01643-33380

WASHER

19

707-58-17050

ROD,PISTON

19

21N-63-62321

ROD,PISTON

20

707-46-16030

BUSHING

21

707-46-16040

BUSHING

22

707-77-16010

SEAL,DUST (KIT)

23

07043-00108

PLUG

24

707-36-25230

PISTON

24

707-36-25110

PISTON

25

07000-15160

O-RING (KIT)

25

07000-15145

O-RING (KIT)

26

07001-01560

RING,BACK-UP (KIT)

26

707-35-91550

RING,BACK-UP (KIT)

27

707-44-25910

RING

28

707-39-25011

RING,WEAR (KIT)

29

707-44-25180

RING,PISTON (KIT)

30

707-40-28020

SPACER

31

707-36-25150

PISTON

32

707-71-50400

PLUNGER

33

04260-01270

BALL

34

707-71-91380

PIN

34

707-71-91390

PIN

35

707-71-61800

PLUNGER

35

707-71-51852

PLUNGER

36

01253-61630

BOLT

37

21N-63-62371

TUBE

38

07000-13048

O-RING (KIT)

39

01010-81450

BOLT

40

01643-31445

WASHER

41

21N-62-18430

BAND

42

21N-63-62390

BRACKET

43

01010-81240

BOLT

44

01643-31232

WASHER

45

176-61-41330

CLAMP

46

01010-81250

BOLT

47

01643-31232

WASHER

48

21N-62-18450

BLOCK

49

07000-12060

O-RING (KIT)

50

01011-81890

BOLT

51

01643-31845

WASHER

52

07371-51470

FLANGE

53

707-88-33060

CAP

54

07371-51470

FLANGE

55

01010-81455

BOLT

56

01643-31445

WASHER

57

01310-01240

SCREW

K

707-98-85310

SERVICE KIT

K

707-99-89250

SERVICE KIT

Выбрано товаров: 70
