Запчасти Komatsu PC1250-8R РУКОЯТЬ (.M) (ДЛЯ ЭКСКАВАТ.) (АВТОМАТИЧ. СМАЗ.)(№-) РАБОЧЕЕ ОБОРУДОВАНИЕ

|$2

21N-947-0032

ARM ASS'Y

1

ARM

2

21N-68-32630

SEAT (WELDED)

3

21N-68-32650

SEAT (WELDED)

4

21N-70-32160

BLOCK (WELDED)

5

21N-70-35250

SEAT (WELDED)

6

21N-947-3550

BRACKET (WELDED)

7

154-54-18510

SEAT (WELDED)

8

209-70-57170

SEAT (WELDED)

9

209-72-15120

SEAT (WELDED)

10

21N-70-32150

BUSHING

11

07020-00000

FITTING

12

21N-70-12170

BUSHING

13

07020-00000

FITTING

14

21N-70-11181

BUSHING

15

209-72-11261

SEAL

16

21N-70-12160

SEAL

17

209-72-11261

SEAL

18

209-72-11311

SEAL

19

21N-70-11210

PLATE

20

01010-82455

BOLT

21

01643-32460

WASHER

22

21N-70-31171

PIN

23

21N-72-11210

SHIM, 1.0MM

24

21N-70-32140

PIN

25

207-70-11340

SPACER, 0.8MM

26

21N-70-11230

PLATE

27

01010-81640

BOLT

28

01643-31645

WASHER
