Запчасти Komatsu PC1250-8R МЕХАНИЗМ ПОВОРОТА (ЗАДН.)(№-) ПОВОРОТН. КРУГ И КОМПОНЕНТЫ

1

208-26-63170

CASE

2

06000-23124

BEARING

3

21N-26-31140

BEARING

4

208-26-52263

COVER

5

01010-81040

BOLT

6

01643-31032

WASHER

7

208-26-61291

OIL SEAL

8

21N-26-31110

SHAFT, 13 TEETH

9

208-26-61151

COUPLING

10

208-26-52230

PLATE

11

205-32-51211

BOLT

12

207-27-63170

CARRIER

13

208-26-63140

GEAR

14

207-27-63210

BEARING

15

20Y-27-21250

WASHER

16

207-27-63230

PIN

17

20Y-26-21330

PIN

18

207-27-63150

GEAR

19

207-27-63250

WASHER

20

208-26-63131

GEAR

21

20Y-27-13310

WASHER

22

208-26-63150

CARRIER

23

208-26-63120

GEAR

24

20Y-27-22210

BEARING

25

20Y-27-21240

WASHER

26

20Y-27-21220

PIN

27

20Y-27-21280

PIN

28

208-26-63110

GEAR

29

20Y-27-11250

SPACER

30

208-26-63161

COVER

31

01011-61880

BOLT

32

01643-31845

WASHER

33

07730-40004

VALVE

34

07270-21590

TUBE

35

07281-00197

CLAMP

36

07000-15335

O-RING

37

21N-26-33210

GAUGE

38

21N-26-33220

FILLER

39

07286-01085

HOSE

40

07285-00130

CLIP

41

6138-55-7610

NIPPLE

42

07030-00252

BREATHER

43

08034-40521

BAND

44

01010-82485

BOLT

45

01643-32460

WASHER
