Запчасти Komatsu PC1250-8 ГИДР. БАК., ВОЗВРАТ. ФИЛЬТР. (№8-) ГИДР. БАК., ЗАПЫЛЕНН МЕСТН. ARRANGEMENT, ЕС ARRANGEMENT

1

21N-60-41121

Case

2

21N-60-41131

Cover

3

07000-15180

O-ring

4

01010-81235

Bolt

5

01643-31232

Washer

6

07069-34057

Spring

7

20Y-60-31131

Valve Assembly

8

20Y-60-31140

Strainer

9

209-60-77532

Element

9

209-60-77310

Valve Assembly

10

04065-04218

Ring, Snap

11

208-60-51411

Poppet

12

208-60-51420

Collar

13

209-60-77320

Spacer

14

708-1D-14130

Spring

15

07042-30211

Plug, Taper

16

208-60-61321

Bracket

17

01010-81025

Bolt

18

01643-31032

Washer

19

07000-12095

O-ring

20

07000-12060

O-ring

21

01010-81245

Bolt

22

01643-31232

Washer

23

21N-60-41140

Bracket

24

01010-81255

Bolt

25

01011-81205

Bolt

26

175-54-34170

Washer

|$27

21N-60-12201

Filter Assembly

|$28

21N-60-12200

Filter Assembly

27

103-60-23250

Base

28

103-60-23260

Valve

29

21N-60-12211

Filter

29

21N-60-12210

Cartridge

30

07000-13032

O-ring

31

01010-81030

Bolt

32

01643-31032

Washer

33

07002-13334

O-ring

34

21N-62-31892

Tee

35

7861-93-3320

Sensor, Oil Temperature
