Запчасти Komatsu PC1250-8 РАБОЧЕЕ ОБОРУДОВАНИЕ, ЦИЛИНДР РУКОЯТИ, ПРАВ. (№8-) РАБОЧЕЕ ОБОРУДОВАНИЕ, ДЛЯ ПРЯМАЯ ЛОПАТА CONFIGURATION

|$0

21N-63-03121

Cylinder Assembly

1

21N-63-66340

Cylinder

2

21N-63-66320

Rod, Piston

3

707-46-11510

Bushing

4

07043-00108

Plug, Taper

5

707-46-11510

Bushing

6

07043-00108

Plug, Taper

7

707-71-51860

Plunger

8

04260-01270

Ball

9

707-71-91510

Cap

10

707-27-18970

Cylinder Head

11

07179-14146

Ring, Snap

12

707-56-13740

Seal, Dust, (Kit : K14)

13

707-52-91071

Bushing

14

707-51-13030

Packing, Rod, (Kit : K14)

15

707-51-13640

Ring, Buffer, (Kit : K14)

16

07000-15175

O-ring, (Kit : K14)

17

707-35-91840

Ring, Back-up, (Kit : K14)

18

01011-82400

Bolt

19

707-88-75410

Washer

20

707-36-18600

Piston

21

707-44-18280

Ring, Piston, (Kit : K14)

22

707-39-18830

Ring, Wear, (Kit : K14)

23

707-44-18920

Ring

24

07000-15120

O-ring, (Kit : K14)

25

07001-05120

Ring, Back-up, (Kit : K14)

26

01310-01225

Screw

27

21N-63-66470

Tube,R.H.

28

21N-62-13241

Tube

29

07372-21060

Bolt

30

01643-51032

Washer

31

07000-13035

O-ring, (Kit : K14)

32

01010-81450

Bolt

33

01643-31445

Washer, Flat

34

07000-13048

O-ring, (Kit : K14)

35

21N-63-66390

Bracket

36

707-88-21090

Band

37

07372-21240

Bolt

38

01643-51232

Washer

39

07283-33442

Clip, Pipe

40

01597-01009

Nut

41

01643-31032

Washer

42

07282-14311

Clamp, Pipe

43

01010-81020

Bolt

44

01643-31032

Washer

45

707-88-33050

Cap

46

07371-51260

Flange, Split

47

01010-81245

Bolt

48

01643-31232

Washer

49

707-88-33060

Cap

50

07371-51470

Flange, Split

51

01010-81455

Bolt
